The shale shakers performance can be easily observed, all aspects of its operation are visible. Shale shakers provide the advantage of not degrading soft or friable cuttings. When well operated and maintained,shale shakers can produce a relatively dry cuttings discharge.
In unweighted muds, the shale shaker’s main role is to remove as much solids as possible and reduce the solids loading to the downstream hydrocyclones and centrifuges to improve their efficiency. In muds containing solid weighting agents such as barite, the shale shaker is the primary solids removal device. It is usually relied upon to remove all drilled cuttings coarser than the weighting material. Downstream equipment will often remove too much valuable weighting material.Enough shakers should be installed to process the entire circulating rate with the goal of removing as many drilled cuttings as economically feasible. Given the importance of the shale shaker, the most efficient
shakers and screens should be selected to achieve optimum economic performance of the solids control system.
Shaker performance is a function of:
- Vibration pattern
- Vibration dynamics
- Deck size and configuration
- Shaker screen characteristics
- Mud rheology (plastic viscosity)
- Solids loading rate (penetration rate, hole diameter)
The impact of each is discussed in detail in this chapter. Guidelines for shaker and screen selection are also provided.Simply stated, a shale shaker works by channelling mud and solids onto vibrating screens. The mud and fine solids pass through the screens and return to the active system. Solids coarser than the screen openings are conveyed off the screen by the vibratory motion of the shaker. The shaker is the only solids removal device that makes a separation based on physical particle size. Hydrocyclones and centrifuges separate solids based on differences in their relative mass.
Read more for GN Shale Shakers
You will read more info. for the shale shaker screens available manufactured by GN Solids Control.
written by GN solids Control
\\ tags: shale shaker
Solids control system will meet different cutting point when running
Shale shaker use for size>70 micron solid particle as the important part of total system
As the first step,GN shale shaker use linear motion,can remove the big size cuttings,and keep high effectiveness,work for second step of whole system,solid&liquid separate result will effect rest solids control step
The applicable range of drilling fluid vibrating screen:
Ground / offshore oil / gas drilling / CBM excavation / Trenchless Directional Crossing / piling / waste water / mud treatment etc., primary and two or three stage solids handling of mud and liquid to be treated. mostly, it is the primary treatment of mud and solid liquid mixtures applicable to various environments.
Function
The performance can be expected and operation direct to watch . Shale shakers provide the advantage of not,easy manage and maintain,shale shakers can produce a sure dry cuttings discharge.equipment’s main job is remove as much solids as possible and reduce the solids loading to the next level, the shale shaker is the primary solids removal device. It is usually relied upon to remove all drilled cuttings coarser than the weighting material. Downstream equipment will often remove too much valuable weighting
Numbers shaker should be installed to process the whole circulating with the target of removing as much drilled cuttings as economically feasible. because as the important part of the system, need arrange enough quantity shale shaker and put at suitable place to achieve optimum economic performance of the solids control system.
The working principle
mainly by the screen frame, screen exciter, damping element composed of drilling fluid shaker, by the mechanical vibration is bigger than the mesh of solid and solid adsorption by mesh sieve out some less than. The drilling fluid returned from the well head flows from the feed tank to the surface of the vibrating screen. The solid phase is discharged from the tail of the screen and contains a liquid phase smaller than the solid phase of the mesh. The sieve flows into the drilling fluid system to complete the separation.
Safety operation of shale shaker for drilling fluid:
It must be determined that the transport locking device is removed prior to use. The equipment can not be repaired, moved or even removed by the use of the vibrating screen. The equipment shall be operated and maintained according to the safety instructions and warning signs given on the equipment.
Maintenance of mud drilling fluid vibrating screen:
According to the vibration motor safety warning, the motor rules, reasonable maintenance, such as filling lubricating oil, etc.;
In the process of use, the screen should be carefully observed, inspection and so on. The damaged screen mesh and the completely damaged screen shall be repaired or replaced in time;
Make necessary cleaning of vibrating screen and screen so that the screen can have a longer life, after each end.
In order to make the use of vibration screen to achieve the best, regularly and systematically monitor the overall situation of the vibration sieve and maintenance.
written by GN solids Control
\\ tags: shale shaker, Solids control
About 5 years ago, one old client from India bought 2sets complete mud tank system for their oil drilling rigs. During the past years, we continuously support the client with timely after sales service, and offer requested spare parts in shortest time. The client knows GN many years, and IS satisfy with the past experience with GN. Recently, the client get new project and want to renew the mud tank system. New order of several sets shale shaker & mud cleaner issued to GN, including some centrifugal pump, shear pump, mud hopper, mud agitators etc.
Continue reading »
written by admin
\\ tags: mud system, shaker screen, shale shaker, Solids control
GN Solids Control is China & USA based leading brand for solids control equipment. In the past 10 years, GN committed himself to support the worldwide market and win good reputation, especially in global market.
Even the market is down now, GN show positive attitude for the upcoming requirement in next year. To support the market well, shorten the delivery time, accelerating the turnover of capital for clients, GN stock agitator and mud hopper for upcoming requirements. Before stocking of this small equipment, we already have a good quantity of stock for shale shakers, mud cleaners, decanter centrifuges, vertical cuttings dryers etc.
1) GN shale shaker & mud cleaner in stock
GN shale shaker main components are ready for fast assembly and fast delivery. This is good stock. After we have enquiry from clients, we can buy the proper model electrical motor, and finis the assembly and test in about one week. This really help a lot for the turnover of capital for clients.
GN mud cleaner have the same prepare module. We also have good stock for desander cones and desilter cones.
2) GN decanter centrifuge in stock
Decanter centrifuge is the most expensive item in solids control equipment line. Many overseas client rent centrifuge from centrifuge Rental Company, one time price better and very fast delivery. However, GN stock centrifuge may contribute to the purchase from clients. As for price, the cost of one set centrifuge may equal to about 3 times rental cost, it is better clients buy their own centrifuge for long term application, at least 3-5 years. As for delivery, GN stock centrifuge can give very fast delivery.
3) GN vertical cuttings dryer in stock
As the much lower oil price, the drilling waste management market should be pretty cold for long time. Anyway, we will give good service when have requirement from clients.
written by admin
\\ tags: centrifuge, cutting dryer, mud cleaner, shale shaker, Solids control
Russia oil drilling market prefers to buy more and more solids control equipment from China as the strained relationship between Russia and US. Since 2014, The sales amount to Russia have a big percentage for our exporting business.
1)Mud Cleaner:
GN Mud cleaner is combination of shale shaker, desander cones and desilter cones. Three units in one make the footprint much smaller, save lots of space for the surface of mud tank system.
GN have different type shale shaker, with 2 panel, 3 panel or 4 panel. Thus, the mud cleaner is also different which can be 2 panel, 3 panel or 4 panel deck shaker.
The mud cleaner treating capacity also decided by the desander cones qty or desilter cones qty, which can be 200gpm, 500gpm, 800gpm,1000gpm or 1500gpm. We can control the treating capacity by the quantity of desander or desilter.
2) Decanter centrifuge
GN Decanter centrifuge have different options. For oil drilling, the most popular centrifuge model is GNLW363 and GNLW452. GNLW363 is high speed centrifuge with 14inch bowl size and can be used with fixed speed control panel or variable speed control panel; GNLW452 is middle speed centrifuge which is specialized for barite recovery or big solids separation.
Except for above two model centrifuge, we also have another model centrifuge in different bowl size. Pls check more from GN website: GN Decanter centrifuge
3) Vertical cuttings dryer:
GN vertical cuttings dryer is used for drilling waste management. As to support the environmental protection, we design the machine as per the request from government policy. Up to now, the centrifuge show super working performance when deal with oil based mud drilling cuttings, saving lots of cost for clients on the OBM drilling cuttings treatment, in separation and transportation.
If you need any support on solids control or drilling waste management, pls contact us freely.
written by admin
\\ tags: centrifuge, cutting dryer, mud cleaner, shale shaker, Solids control
GN can offer various type shaker screens for different model shale shakers. Recently, we have one client from Middle East with 5 land rigs under drilling. He visited our company at the end of last year, and he knows GN very well. At the first, the client need equipment for oily sludge treatment, they failed to win the tender. Next time they need some sets of decanter centrifuges & high G drying shakers, but they are busy with big tender for chemical supply and they lose the centrifuge tender again. We really feel sorry to hear that.
After about half years past, the client needs to buy some screens sample for their rigs working in Oman. And we want to catch this opportunity and start to offer products to them. The client need 20pcs replacement shaker screen for Brandt VENOM shaker (API 70) and 20pcs replacement shaker screen for Brandt VENOM shaker (API 80). We can offer both composite material frame screen and carbon steel frame screen. In fact, the carbon steel frame screen is not feedback good in some mud condition, even the price of composite material is higher, we recommend client the composite material screen with much better and reliable working performance.
Except for Venom shaker, GN can also offer other different models of replacement shaker screen. For example:
1) Replacement screen for Derrick FLC 2000 shale shakers, pyramid screen and flat screen.
2) Replacement screen for Derrick FLC 500 shale shakers, pyramid screen and flat screen.
3) Replacement screen for Swaco Mongoose, omposite material screen or Carbon steel frame screen, different price, different lifetime and different working performance. We recommend composite as better choice
4) Replacement screen for Brandt king cobra/ Brandt Venom, composite material screen or Carbon steel frame screen, different price, different lifetime and different working performance. We recommend composite as better choice
5) Except for above screens, GN can offer replacement screen for Scomi shakers, FSI shale shakers
written by admin
\\ tags: decanter centrifuge, oily sludge treatment, shaker screen, shale shaker
GN Solids Control has been working for solids control equipment for many years. With rich experience, GN can design good performance solids control equipment, with much proper production material and reasonable price. Recently, we export one batch of solids control equipment to Middle East clients.
1) Middle Speed Decanter Centrifuge
The client is local HDD contractor with some HDD drilling rigs. At the beginning of this year, they got one big project for gas pipelines from local government and they realize the necessary of one set middle speed decanter centrifuge to continue the work. After several rounds discussion, the client finally choose 18inch decanter centrifuge GNLW452C-VFD. This model centrifuge can have bowl speed from 0 to 1800RPM; treating capacity can reach to 60m3/h, equal to 260gpm. The centrifuge is equipped with one 45kw motor, total energy consumption is also lower than dual motor centrifuge.
Continue reading »
written by admin
\\ tags: centrifugal pump, centrifuge, mud system, shale shaker, Solids control
As China & USA leading supplier for solids control equipment and drilling waste management equipment, GN Solids Control just deliver large quantity of solids control equipment to Middle East, the clients have been in connection with GN Solids Control for over 5 years. Even the market is down, the client still buy some solids control equipment for the ongoing drilling operation. In this year, the clients bought some shale shakers, mud agitators, mud gun, centrifugal pumps etc.
Continue reading »
written by admin
\\ tags: centrifugal pump, mud agitator, shale shaker, Solids control, waste management
The client is local drilling client for HDD project. The client is providing water well drilling contract to government companies, government oil drilling companies etc. Last year in Feb, 2015, the client bought two sets mud cleaning system. Each set mud system only with one mud recycling tank, mounting with one set shale shaker & one set mud cleaner.
Recently, the client is requiring one more compact mud system for water well drilling, 500gpm system with two tanks. One shaker tank is with shale shaker and mud cleaner, one mud mixing tank with agitators or centrifugal pumps.
Simple introduction of GN 500gpm mud system as below.
One shale shaker mud tank system including: one set shale shaker, one set mud cleaner, two sets centrifugal pumps. The shale shaker is GN patent 3 panel shale shaker, which have over 5 years jobsite experience. The shaker can work well in different hard conditions. The mud cleaner is GN 3 panel mud cleaner with GN compact design, down deck shaker and desilter cones. Another tank is mud mixing tank with mud agitators, mud guns and mud hopper for chemical mixing.
Except for this mud system, GN drilling waste management equipment is also very popular in the world.
Waste management centrifuge: GN decanter centrifuge is working after replacing USA brand centrifuges. The centrifuge can work for solids control, waste management, waste water treatment ect. In solids control application, 2500rpm is generally used for mud weight cutting, and 1800rpm to 2000rpm is generally used for barite recovery. In drilling waste management, 2500rpm to 3000rpm is generally used for removal the fine solids. In waste water treatment, higher speed centrifuge is required after chemical enhancement.
Vertical cuttings dryer is also called VG dryer, VG dryer can treat the drilling cuttings discharged from shale shaker, the OOC after VG dryer can reduce to about 3% to 5%, and the dry solids can be collected by cuttings skips and transport by trucks to a cuttings center for final treatment.
written by admin
\\ tags: centrifuge, mud cleaner, mud system, shale shaker, VG Dryer, waste management
GN Solids Control can produce all of the solids control equipment, eg. Shale shaker, desander, desilter, mud cleaner, centrifuge, agitator, etc. GN four phase solids control mud system is working in over 60 countries and areas with good working performance and reliable lifetime.
GN Solids Control four stage mud recycling system including below parts.
Part 1: shale shaker working on mud tanks, as the first phase mud separation equipment. We have different type shale shaker for option. Including
- a. 2 deck panel shaker which is professional for diamond drilling, or other simple construction project.
- b. 3 deck panel shaker which can be used for workover rig and other project.
- c. 4 deck panel shaker which is most popular for oil drilling circulation mud system and this can also used for drilling waste management.
Part 2: Desander working after shale shaker to give further treatment, as the second phase mud cleaning equipment. We also have different type desanders for option.
- a. desander without deck shaker, cheaper price.
- b. desander with deck shaker, reasonable price with better performance
Part 3: desilter working after desander to give further treatment, as the third phase mud cleaning equipment. We also have different type desitler for option.
- a. desilter without deck shaker, cheaper price
- b. desilter with deck shaker, reasonable price and better performance.
- Remark: we can also offer mud cleaner which is combination of desander & desilter. Smaller footprint, but better performance.
Part 4: Decanter centrifuge after desilter to give further treatment, as the fourth phase mud cleaning equipment. We have different type centrifuge for options.
- a. GNLW223 baby mini centrifuge for diamond drilling
- b. GNLW363 centrifuge which is most popular model for solids control / drilling waste management, GNLW363 is replacement for Derrick DE1000 centrifuge, etc.
- c. GNLW453 and GNLW553 is GN big bowl big volume centrifuge for special requirements
- d. GNLW452 centrifuge is middle speed centrifuge which is professional for barite recovery for oil drilling.
Any requirements, pls contact us freely
written by admin
\\ tags: centrifuge, desander, desilter, mud system, shale shaker
|
